CCM001

PAD100
pneumatic actuator series PAD; ATEX II 2 G/D; double acting; rotation angle 90°; according to ISO 5211/NAMUR; operating pressure range max. 8bar; diameter 100mm; flange ISO5211 F07/F10; female square 17mm; torque at 5,5bar 150Nm
V46L2-11
5/3-way valve; according to NAMUR; pilot-operated; pressure range 2,5...8bar; actuation electrical/electrical; standard coil D; connector size 22mm; connection 1/4"; nominal diameter 7mm; central position closed; flow rate 850Nl/min
D24VDC
coil type D; connector size 22mm; voltage 24VDC
C002-31-LV-2
connector; connector size 22mm; with integrated LED-yellow and VDR; voltage 24VAC/DC
RI3372
mounting kit; inductive dual proximity switch IFM; actuator 52-100
