Change-over contact; Connection Brass; Setting scale; 250VAC/6A; 24VDC/2A; Protection class See Protection cap (Max. IP65)
Vacuum switch Series VS01 -
Other materiales - A06
-
Float PVDF; Female thread Malleable cast iron zinc plated; Scale for air at 6 bar/20°C; Pressure Max. 10bar; Mounting position Vertical pipe; Temperature range +5...+75°C; Application: Air
Flow meter Series FM06/FM07 -
Female thread; Body Nickel plated brass; Temperature Max. +90°C; Application: WaterFlow indicator Series FAA
-
Digital display, 4 digits; Wetted parts Stainless steel 1.4404; 2 Freely adjustable switching outputs (PNP/NPN); Reversible display bar/PSI, Accuracy 0,5% of full pressure range; Window/hysteresis function free programmable; Power supply 15...35VDC; Electric connection M12 (IP67) 4-pin; Pressure range -1...0bar
Electronic pressure switch Series PS17 -
Body Nickel plated brass; Medium temperature Max. 90°C; Application: WaterFlow indicator Series FM26
-
Body, Wetted parts Stainless steel 1.4571; Outlet signal 4...20 mA Proportional to applied pressure; Male thread 1/2"; Accuracy 0,5% of full pressure rangePressure transmitter Series PT08
-
Temperature range -10…+100°C; Pressure Max. 16bar; Application: Water; Pressure drop 0,25Bar
Flow indicator Series FM25 -
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contact
Flow monitors With Inspection glass Series RVO/U -
Connections, Float Stainless steel AISI 316Ti; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors With Inspection glass Series RVO/U
-
Body, Wetted parts Stainless steel 1.4404; Outlet signal 4...20 mA Proportional to applied pressure; Accuracy 0,5% of full pressure rangePressure transmitter Series PT04
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors With Inspection glass Series FM10-N
-
Viscosity compensated ...600mm²/s; Body Nickel plated brass; For any mounting position; Medium temperature Max. 120°C; Oil scale; Application: Monitoring of lubrication
Flow monitors Series FM24 -
Viscosity compensated ...600mm²/s; Body Stainless steel 1.4571; For any mounting position; Medium temperature Max. 120°C; Oil scale; Application: Monitoring of lubricationFlow monitors Series FM24
-
Change-over contact; Connection Brass; Setting scale; 250VAC/6A; 24VDC/2A; Protection class See Protection cap (Max. IP65)
Pressure switch Series PS01 -
Body, Wetted parts Stainless steel 1.4404; Pressure sensor Stainless steel AISI 316L; Seal NBR; Outlet signal 0...10V Proportional to applied pressure; Male thread 1/4"; Accuracy 1% of full pressure rangePressure transmitter Series PT02
-
Viscosity compensated 32...600mm²/s; Body Nickel plated brass; For any mounting position; Medium temperature Max. 120°C; Oil scale; NO contact; Application: Monitoring of lubricationFlow monitors Series FM03-N
-
Viscosity compensated 32...600mm²/s; Body Stainless steel AISI 316Ti; For any mounting position; Medium temperature Max. 120°C; Oil scale; NO contact; Application: Monitoring of lubricationFlow monitors Series FM03-W
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; Change-over contact
Flow monitors With Inspection glass Series RVO/U-MS-W -
Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 120°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contactFlow monitors Series FM02-N
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contactFlow monitors With Inspection glass Series FM42-N
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Air scale; Switching range at 1 bar absolute; 20°C; Change-over contactFlow monitors With Inspection glass Series FM42-N
-
Connections, Float Stainless steel AISI 316Ti; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors With Inspection glass Series FM10-W
-
Brass; Female thread/Male thread
Flow limiter Series BB -
Brass; Female threadFlow limiter Series BA
-
Suitable for Compressors; 3-pin; Protection class IP54; Switching capacity for 3-phase current 7,5kW (400V), At AC 2,2kW (230V); Hysteresis range adjustable; Overpressure protection 35bar; Female thread 1/2"; Motor protection relay; Relief valve; Mechanical ON/OFF-switch
Pressure switch Series MDR3 -
Brass; Male thread
Flow limiter Series BC -
Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contact
Flow monitors Series FM01-N -
Body, Float Stainless steel 1.4571; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors Series FM01-W
-
Viscosity compensated 32...600mm²/s; Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 120°C; Oil scale; NO contact
Flow monitors Series FM13-N -
Body Nickel plated brass; Float Brass; Vertical mounting; Medium temperature Max. 100°C; Water scale; NO contactFlow monitor with flow indicator Series FM18-N
-
Body Nickel plated brass Float POM; For any mounting position; Medium temperature Max. 80°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contact;Flow monitors Series FM30
Other materiales - A06
Vacuum switch Series VS01
Change-over contact; Connection Brass; Setting scale; 250VAC/6A; 24VDC/2A; Protection class See Protection cap (Max. IP65)
| Connection | Hysteresis range | Overpressure protection | Diaphragm | Range of adjustment | Type | Sequence |
|---|---|---|---|---|---|---|
| G 1/4" | 3 mbar | 0,5 bar | NBR | -5...-20 mbar | VS01-14N-5/20 | 32940001 |
| G 1/8" | 10 mbar | 0,5 bar | NBR | -25...-100 mbar | VS01-18N-25/100-01 | 32940002 |
| G 1/8" | 30 mbar | 1 bar | NBR | -100...-300 mbar | VS01-18N-100/300 | 32940003 |
| G 1/4" | 10 mbar | 4 bar | NBR | -25...-100 mbar | VS01-14N-25/100-01 | 32940004 |
| G 1/8" | 75 mbar | 1 bar | Silicone | -300...-700 mbar | VS01-18S-300/700-01 | 32940005 |
Flow meter Series FM06/FM07
Float PVDF; Female thread Malleable cast iron zinc plated; Scale for air at 6 bar/20°C; Pressure Max. 10bar; Mounting position Vertical pipe; Temperature range +5...+75°C; Application: Air
| Type | Sequence |
|---|---|
| FM06-10-M-30-01 | 32950000 |
| FM06-10-PV-18-01 | 32950001 |
| FM06-10-PV-11-01 | 32950002 |
| FM06-S25-PV-18 | 32950003 |
| Connection | Operating pressure | Range | Type |
|---|---|---|---|
| G 1" | 0...5 bar | 6...60 l/min | FAA25-MS |
| Connection | Pressure range | Range of adjustment | Type |
|---|---|---|---|
| G 1/4" | - | -1...0 bar | PS17-14N-V0 |
Flow indicator Series FM26
| Connection | Length | Maximum pressure | Indicating range | Type | Sequence |
|---|---|---|---|---|---|
| 1/4" | 59 mm | 10 bar | 1...10 l/min | FM26-14-N-10 | 32980000 |
| 1/2" | 71 mm | 8 bar | 3...30 l/min | FM26-15-N-30 | 32980001 |
| 3/8" | 71 mm | 8 bar | 2...20 l/min | FM26-38-N-20 | 32980002 |
Pressure transmitter Series PT08
| Measuring range | Type | Sequence |
|---|---|---|
| 0...10 bar | PT08-12N-010-420 | 32990000 |
| 0...0,25 bar | PT08-12N-0,25-420 | 32990001 |
| 0...250 bar | PT08-12N-250-420 | 32990002 |
| -1...0 bar | PT08-12N-V-420 | 32990003 |
| -1...0 bar | PT08-12N-100V0,1-01 | 32990004 |
| -1...0 bar | PT08-12N-0,16-420 | 32990005 |
