BA892-50-T0

Name: BA892-50-T0
SKU: BA892-50-T0
Price: 2032.6 EUR
Availability: InStock

flanged ball valve with pneumatic actuator series BA892; NO; flange PN40; body, ball AISI 316; seals PTFE-reinforced/FKM; compensation hole; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...40bar; nominal diameter 50mm; length 82mm; actuator PAS1405; free of oil and grease for oxygen

Intrastat No.: 84818081
Country of origin: Italy
Weight: 23.42 Kg
Short Itemnumber:BA89250T0

2.032,60 € 2032.6 EUR 2.032,60 €

DN
- 50 mm
Length
- 82 mm
Pressure range
- 0...16 bar
Actuator
- PAS1005

This combination does not exist.

Availability:

Add to Cart

Specifications
Spare Parts

dimension
DN	50 mm
Length	82 mm
pressure
Pressure range	0...16 bar
characteristics
Actuator	PAS1005

BA892-50-L x 1.0

BA892-50-L

flanged ball valve series 721000; flange PN40, full bore; body, ball AISI 316; seals PTFE-reinforced/FKM; compensation hole; pressure range 0...40bar; medium temperature -20...+160°C; nominal diameter 50mm; length 82mm; free of oil and grease for oxygen

Add to Cart

PAS1405 x 1.0

Pneumatic actuator PAS1405

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 140mm; Flange ISO5211 F10/F12; Female square 27mm; Torque at 5,5bar 114Nm

Add to Cart

A4/535/07 x 1.0
